AC brushless rotary servo motor with straight shaft + built-in absolute feedback encod. (17-bit) + oil seal - Mitsubishi Electric (MELSERVO JE series) - Rated output 2000W / 2kW - 131072ppr (equivalent to 17-bit) feedback - Rated current 9.6A - Supply voltage 200Vac class - Rated torque 9.55Nm nominal - Rated rotational speed 2000rpm - 176x176mm flange mounting - IP67 - rated for 0...+40°C ambient

SRVMTR 2KW,2KRPM,200V,BRK,OIL SEAL

AC brushless rotary servo motor with straight shaft + built-in e/m brake + built-in absolute feedback encod. (17-bit) + oil seal - Mitsubishi Electric (MELSERVO JE series) - Rated output 2000W / 2kW - 131072ppr (equivalent to 17-bit) feedback - Rated current 9.6A - Supply voltage 200Vac class - Rated torque 9.55Nm nominal - Rated rotational speed 2000rpm - 176x176mm flange mounting - IP67 - rated for 0...+40°C ambient

AC brushless rotary servo motor with keyed shaft + built-in absolute feedback encod. (17-bit) + oil seal - Mitsubishi Electric (MELSERVO JE series) - Rated output 1500W / 1.5kW - 131072ppr (equivalent to 17-bit) feedback - Rated current 9.4A - Supply voltage 200Vac class - Rated torque 7.16Nm nominal - Rated rotational speed 2000rpm - 130x130mm flange mounting - IP67 - rated for 0...+40°C ambient

AC brushless rotary servo motor with straight shaft + built-in absolute feedback encod. (17-bit) + oil seal - Mitsubishi Electric (MELSERVO JE series) - Rated output 1500W / 1.5kW - 131072ppr (equivalent to 17-bit) feedback - Rated current 9.4A - Supply voltage 200Vac class - Rated torque 7.16Nm nominal - Rated rotational speed 2000rpm - 130x130mm flange mounting - IP67 - rated for 0...+40°C ambient

SRVMTR 1.5KW,2KRPM,200V,BRK,OIL SEAL

AC brushless rotary servo motor with straight shaft + built-in e/m brake + built-in absolute feedback encod. (17-bit) + oil seal - Mitsubishi Electric (MELSERVO JE series) - Rated output 1500W / 1.5kW - 131072ppr (equivalent to 17-bit) feedback - Rated current 9.4A - Supply voltage 200Vac class - Rated torque 7.16Nm nominal - Rated rotational speed 2000rpm - 130x130mm flange mounting - IP67 - rated for 0...+40°C ambient

AC brushless rotary servo motor with keyed shaft + built-in absolute feedback encod. (17-bit) + oil seal - Mitsubishi Electric (MELSERVO JE series) - Rated output 1000W / 1kW - 131072ppr (equivalent to 17-bit) feedback - Rated current 5.6A - Supply voltage 200Vac class - Rated torque 4.77Nm nominal - Rated rotational speed 2000rpm - 130x130mm flange mounting - IP67 - rated for 0...+40°C ambient

AC brushless rotary servo motor with straight shaft + built-in absolute feedback encod. (17-bit) + oil seal - Mitsubishi Electric (MELSERVO JE series) - Rated output 1000W / 1kW - 131072ppr (equivalent to 17-bit) feedback - Rated current 5.6A - Supply voltage 200Vac class - Rated torque 4.77Nm nominal - Rated rotational speed 2000rpm - 130x130mm flange mounting - IP67 - rated for 0...+40°C ambient

AC brushless rotary servo motor with keyed shaft + built-in e/m brake + built-in absolute feedback encod. (17-bit) + oil seal - Mitsubishi Electric (MELSERVO JE series) - Rated output 1000W / 1kW - 131072ppr (equivalent to 17-bit) feedback - Rated current 5.6A - Supply voltage 200Vac class - Rated torque 4.77Nm nominal - Rated rotational speed 2000rpm - 130x130mm flange mounting - IP67 - rated for 0...+40°C ambient

AC brushless rotary servo motor with straight shaft + built-in e/m brake + built-in absolute feedback encod. (17-bit) + oil seal - Mitsubishi Electric (MELSERVO JE series) - Rated output 1000W / 1kW - 131072ppr (equivalent to 17-bit) feedback - Rated current 5.6A - Supply voltage 200Vac class - Rated torque 4.77Nm nominal - Rated rotational speed 2000rpm - 130x130mm flange mounting - IP67 - rated for 0...+40°C ambient

AC brushless rotary servo motor with keyed shaft + built-in absolute feedback encod. (22-bit) + oil seal - Mitsubishi Electric (MELSERVO J4 series) - Rated output 5000W / 5kW - 22-bit (equivalent to 4194304ppr) feedback - Rated current 28A - Supply voltage 200Vac class - Rated torque 15.9Nm nominal - Rated rotational speed 3000rpm - 130x130mm flange mounting - IP65 - with MS-type connectors - rated for 0...+40°C ambient - equivalent to HGRR503K

AC brushless rotary servo motor with keyed shaft + built-in e/m brake + built-in absolute feedback encod. (22-bit) + oil seal - Mitsubishi Electric (MELSERVO J4 series) - Rated output 5000W / 5kW - 22-bit (equivalent to 4194304ppr) feedback - Rated current 28A - Supply voltage 200Vac class - Rated torque 15.9Nm nominal - Rated rotational speed 3000rpm - 130x130mm flange mounting - IP65 - with MS-type connectors - rated for 0...+40°C ambient - equivalent to HGRR503BK

AC brushless rotary servo motor with straight shaft + built-in e/m brake + built-in absolute feedback encod. (22-bit) + oil seal - Mitsubishi Electric (MELSERVO J4 series) - Rated output 5000W / 5kW - 22-bit (equivalent to 4194304ppr) feedback - Rated current 28A - Supply voltage 200Vac class - Rated torque 15.9Nm nominal - Rated rotational speed 3000rpm - 130x130mm flange mounting - IP65 - with MS-type connectors - rated for 0...+40°C ambient - equivalent to HGRR503B

AC brushless rotary servo motor with straight shaft + built-in absolute feedback encod. (22-bit) + oil seal - Mitsubishi Electric (MELSERVO J4 series) - Rated output 5000W / 5kW - 22-bit (equivalent to 4194304ppr) feedback - Rated current 28A - Supply voltage 200Vac class - Rated torque 15.9Nm nominal - Rated rotational speed 3000rpm - 130x130mm flange mounting - IP65 - with MS-type connectors - rated for 0...+40°C ambient - equivalent to HGRR503

AC brushless rotary servo motor with keyed shaft + built-in absolute feedback encod. (22-bit) + oil seal - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - 22-bit (equivalent to 4194304ppr) feedback - Rated current 23A - Supply voltage 200Vac class - Rated torque 11.1Nm nominal - Rated rotational speed 3000rpm - 130x130mm flange mounting - IP65 - with MS-type connectors - rated for 0...+40°C ambient - equivalent to HGRR353K

AC brushless rotary servo motor with keyed shaft + built-in e/m brake + built-in absolute feedback encod. (22-bit) + oil seal - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - 22-bit (equivalent to 4194304ppr) feedback - Rated current 23A - Supply voltage 200Vac class - Rated torque 11.1Nm nominal - Rated rotational speed 3000rpm - 130x130mm flange mounting - IP65 - with MS-type connectors - rated for 0...+40°C ambient - equivalent to HGRR353BK

AC brushless rotary servo motor with straight shaft + built-in e/m brake + built-in absolute feedback encod. (22-bit) + oil seal - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - 22-bit (equivalent to 4194304ppr) feedback - Rated current 23A - Supply voltage 200Vac class - Rated torque 11.1Nm nominal - Rated rotational speed 3000rpm - 130x130mm flange mounting - IP65 - with MS-type connectors - rated for 0...+40°C ambient - equivalent to HGRR353B

AC brushless rotary servo motor with straight shaft + built-in absolute feedback encod. (22-bit) + oil seal - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - 22-bit (equivalent to 4194304ppr) feedback - Rated current 23A - Supply voltage 200Vac class - Rated torque 11.1Nm nominal - Rated rotational speed 3000rpm - 130x130mm flange mounting - IP65 - with MS-type connectors - rated for 0...+40°C ambient - equivalent to HGRR353

AC brushless rotary servo motor with keyed shaft + built-in absolute feedback encod. (22-bit) + oil seal - Mitsubishi Electric (MELSERVO J4 series) - Rated output 2000W / 2kW - 22-bit (equivalent to 4194304ppr) feedback - Rated current 14A - Supply voltage 200Vac class - Rated torque 6.4Nm nominal - Rated rotational speed 3000rpm - 100x100mm flange mounting - IP65 - with MS-type connectors - rated for 0...+40°C ambient - equivalent to HGRR203K
