AC geared rotary servo motor / gearmotor with straight shaft + built-in e/m brake + built-in absolute feedback encod. (22-bit) + 1/11 high-precision gearhead (flange output) - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - Gear ratio 1/11 (gearhead) - 22-bit (equivalent to 4194304ppr) feedback - Rated current 14A - Supply voltage 200Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 260x260mm flange mounting (grbx. output) - 40arcminutes (0.67°) maximum backlash - IP44 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR352BG1111

AC brushless rotary servo motor with straight shaft + built-in e/m brake + built-in absolute feedback encod. (22-bit) - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - 22-bit (equivalent to 4194304ppr) feedback - Rated current 14A - Supply voltage 200Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 176x176mm flange mounting - IP67 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR352B

AC brushless rotary servo motor with straight shaft + built-in absolute feedback encod. (22-bit) + safety unit compatibility - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - 22-bit (equivalent to 4194304ppr) feedback - Rated current 7A - Supply voltage 400Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 176x176mm flange mounting - IP67 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR3524W0C

AC brushless rotary servo motor with keyed shaft + built-in absolute feedback encod. (22-bit) - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - 22-bit (equivalent to 4194304ppr) feedback - Rated current 7A - Supply voltage 400Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 176x176mm flange mounting - IP67 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR3524K

AC brushless rotary servo motor with keyed shaft + built-in absolute feedback encod. (22-bit) + oil seal - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - 22-bit (equivalent to 4194304ppr) feedback - Rated current 7A - Supply voltage 400Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 176x176mm flange mounting - IP67 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR3524JK

AC brushless rotary servo motor with straight shaft + built-in absolute feedback encod. (22-bit) + oil seal - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - 22-bit (equivalent to 4194304ppr) feedback - Rated current 7A - Supply voltage 400Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 176x176mm flange mounting - IP67 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR3524J

AC geared rotary servo motor / gearmotor with straight shaft + built-in absolute feedback encod. (22-bit) + 1/5 high-precision gearhead (shaft output) - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - Gear ratio 1/5 (gearhead) - 22-bit (equivalent to 4194304ppr) feedback - Rated current 7A - Supply voltage 400Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 120x120mm flange mounting (grbx. output) - 3arcminutes (0.05°) maximum backlash - IP44 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR3524G715

AC geared rotary servo motor / gearmotor with straight shaft + built-in absolute feedback encod. (22-bit) + 1/21 high-precision gearhead (shaft output) - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - Gear ratio 1/21 (gearhead) - 22-bit (equivalent to 4194304ppr) feedback - Rated current 7A - Supply voltage 400Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 170x170mm flange mounting (grbx. output) - 3arcminutes (0.05°) maximum backlash - IP44 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR3524G7121

AC geared rotary servo motor / gearmotor with straight shaft + built-in absolute feedback encod. (22-bit) + 1/11 high-precision gearhead (shaft output) - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - Gear ratio 1/11 (gearhead) - 22-bit (equivalent to 4194304ppr) feedback - Rated current 7A - Supply voltage 400Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 170x170mm flange mounting (grbx. output) - 3arcminutes (0.05°) maximum backlash - IP44 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR3524G7111

AC geared rotary servo motor / gearmotor with straight shaft + built-in absolute feedback encod. (22-bit) + 1/5 high-precision gearhead (flange output) - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - Gear ratio 1/5 (gearhead) - 22-bit (equivalent to 4194304ppr) feedback - Rated current 7A - Supply voltage 400Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 120x120mm flange mounting (grbx. output) - 3arcminutes (0.05°) maximum backlash - IP44 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR3524G515

AC geared rotary servo motor / gearmotor with straight shaft + built-in absolute feedback encod. (22-bit) + 1/21 high-precision gearhead (flange output) - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - Gear ratio 1/21 (gearhead) - 22-bit (equivalent to 4194304ppr) feedback - Rated current 7A - Supply voltage 400Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 170x170mm flange mounting (grbx. output) - 3arcminutes (0.05°) maximum backlash - IP44 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR3524G5121

AC geared rotary servo motor / gearmotor with straight shaft + built-in absolute feedback encod. (22-bit) + 1/11 high-precision gearhead (flange output) - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - Gear ratio 1/11 (gearhead) - 22-bit (equivalent to 4194304ppr) feedback - Rated current 7A - Supply voltage 400Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 170x170mm flange mounting (grbx. output) - 3arcminutes (0.05°) maximum backlash - IP44 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR3524G5111

AC geared rotary servo motor / gearmotor with straight shaft + built-in absolute feedback encod. (22-bit) + 1/6 high-precision gearhead (shaft output) - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - Gear ratio 1/6 (gearhead) - 22-bit (equivalent to 4194304ppr) feedback - Rated current 7A - Supply voltage 400Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 176x176mm flange size with foot mounting (grbx. output) - 40arcminutes (0.67°) maximum backlash - IP44 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR3524G1H16

AC geared rotary servo motor / gearmotor with straight shaft + built-in absolute feedback encod. (22-bit) + 1/59 high-precision gearhead (shaft output) - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - Gear ratio 1/59 (gearhead) - 22-bit (equivalent to 4194304ppr) feedback - Rated current 7A - Supply voltage 400Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 176x176mm flange size with foot mounting (grbx. output) - 40arcminutes (0.67°) maximum backlash - IP44 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR3524G1H159

AC geared rotary servo motor / gearmotor with straight shaft + built-in absolute feedback encod. (22-bit) + 1/43 high-precision gearhead (shaft output) - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - Gear ratio 1/43 (gearhead) - 22-bit (equivalent to 4194304ppr) feedback - Rated current 7A - Supply voltage 400Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 176x176mm flange size with foot mounting (grbx. output) - 40arcminutes (0.67°) maximum backlash - IP44 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR3524G1H143

AC geared rotary servo motor / gearmotor with straight shaft + built-in absolute feedback encod. (22-bit) + 1/35 high-precision gearhead (shaft output) - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - Gear ratio 1/35 (gearhead) - 22-bit (equivalent to 4194304ppr) feedback - Rated current 7A - Supply voltage 400Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 176x176mm flange size with foot mounting (grbx. output) - 40arcminutes (0.67°) maximum backlash - IP44 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR3524G1H135

AC geared rotary servo motor / gearmotor with straight shaft + built-in absolute feedback encod. (22-bit) + 1/29 high-precision gearhead (shaft output) - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - Gear ratio 1/29 (gearhead) - 22-bit (equivalent to 4194304ppr) feedback - Rated current 7A - Supply voltage 400Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 176x176mm flange size with foot mounting (grbx. output) - 40arcminutes (0.67°) maximum backlash - IP44 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR3524G1H129

AC geared rotary servo motor / gearmotor with straight shaft + built-in absolute feedback encod. (22-bit) + 1/17 high-precision gearhead (shaft output) - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - Gear ratio 1/17 (gearhead) - 22-bit (equivalent to 4194304ppr) feedback - Rated current 7A - Supply voltage 400Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 176x176mm flange size with foot mounting (grbx. output) - 40arcminutes (0.67°) maximum backlash - IP44 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR3524G1H117

AC geared rotary servo motor / gearmotor with straight shaft + built-in absolute feedback encod. (22-bit) + 1/11 high-precision gearhead (shaft output) - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - Gear ratio 1/11 (gearhead) - 22-bit (equivalent to 4194304ppr) feedback - Rated current 7A - Supply voltage 400Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 176x176mm flange size with foot mounting (grbx. output) - 40arcminutes (0.67°) maximum backlash - IP44 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR3524G1H111

AC geared rotary servo motor / gearmotor with straight shaft + built-in absolute feedback encod. (22-bit) + 1/6 high-precision gearhead (flange output) - Mitsubishi Electric (MELSERVO J4 series) - Rated output 3500W / 3.5kW - Gear ratio 1/6 (gearhead) - 22-bit (equivalent to 4194304ppr) feedback - Rated current 7A - Supply voltage 400Vac class - Rated torque 16.7Nm nominal - Rated rotational speed 2000rpm - 260x260mm flange mounting (grbx. output) - 40arcminutes (0.67°) maximum backlash - IP44 - with 2 x MS-type connectors - rated for 0...+40°C ambient - equivalent to HGSR3524G116
